Induction motor D 228 [mm] - W 475 [mm]

available with power: 23 - 13 [kW]

Power [kW] 13
Speed [rpm] 2900
Torque [Nm] 43
Peak torque [Nm] 150
Frequency [Hz] 70
Current [A] 400
Bus DC[V] 80
Duty cycle S2-60'
External Diameter [mm] 228
Width [mm] 475
Mass [kg] 77
Attached files
Power [kW] 23
Speed [rpm] 2000
Torque [Nm] 110
Peak Torque  [Nm] 150
Frequency [Hz] 70
Current [A] 400
Bus DC [V] 80
Duty cycle S3-50%
External Diameter [mm] 228
Width [mm] 475
Mass [kg] 77
Attached files
